Jacon Transmix 5000


The Jacon Transmix 5000 is a complete and unique solution to batch mixing and transportation of concrete in mines and tunnels


  • CATERPILLAR C7 diesel rated at 205kw @ 2500 RPM
  • Hydrostatic 4 wheel drive transmission
  • Clark-Hurh steering axles
  • Four Wheel Hydrostatic Steering leaf spring suspension from front and rear cabins
  • SAHR Parking brake with quick release
  • Hydraulically applied four wheel internal wet disc brakes
  • Catalytic converter
  • 12.00 R20, 20 ply tyres
  • Fully operating controls from front and rear cabins
  • Operating and parts manual
  • Water pump and tank
  • 5.0 cubic metre capacity, double spiral blades, hydraulic-drum tilting and capable of batch mixing
  • 20 km/h max road speed
  • Full road lightings/warning stroke lights


  • Mercedes electronic engine
  • Rear driving cabin with full controls
  • Enclosed air conditioned cabin system
  • Fire suppression
