Jacon Shotcrete Transmix 6000 Engineered for Underground

Shotcrete Transmixer 6000

Shotcrete Transmixer TMX 6000

Jacon Shotcrete Transmix 6000

The World’s most compact, low-profile mobile concrete mixer, specifically engineered for underground mining conditions

The Jacon shotcrete Transmix can be optioned with operator stations at both ends at both ends of the transmix, enabling the operator to drive up or down a decline and in and out of a heading without turning the machine around. The Transmix 600o large  agitator bowl allows the machine to carry and batch 6 cubic meter of shotcrete.The Jacon shotcrete Transmix features Rexroth hydraulics which allow formulti-mode, 4-wheel hydrostatic steering. It is capable of reaching speeds of up to 25km/h and handling 1:6 inclines with ease, even when fully laden with 6 cubic metres of concrete while batching. The Transmixer is compact and maneuverable and has the capability to carry consumables for the Shotcrete machine.

Download PDF
